Product Description
Designed for Explosive atmosphere Zone 1, Zone 2
Designed for Groups IIA,IIB,IIC, Temperature classes T1~T4
Designed for sites with explosive atmosphere, such as petroleum exploitation, refinery, storage, chemistry, medicine, military facilities, etc.
Ex-marking | Ex d ib IIC T6 Gb/Ex tD A21 IP66 T80℃ |
Protection grade | IP66 |
Input voltage | AC220V/50Hz |
current | ≤ 1A |
power | ≤ 50W |
Respond frequency | 250-4,000Hz |
material | SS304 |
weight | 15Kg |
gland | M24 M33 |
installation | Wall mount |
Group: IIA IIB IIC | |
Air pressure | 80 ～ 106KPa |
Ambient temperature | -25℃ ~+60℃ |
Relative humidity | ≤ 95%RH(+25℃ ) |
Explosion proof electrical equipment designed and manufactured for installation in hazardous areas with potentially explosive atmosphere are usually very safe. The new standards and directives force manufacturers to put on the market only reliable and safe products, which are realised through consta
READ MORE
Maximum surface temperature of explosion-proof (Ex) equipment can be one of the sufficient causes of explosion if surface temperature is more than the ignition temperature of surrounding explosive atmosphere where Ex equipment installed. Temperature class is given for any Ex equipment/ system on the
READ MORE On and offshore drilling of gas or oil is a high risk sector with respect to fire and explosion hazards. Therefore, the European Union has implemented Directive 92/91/EEC to protect workers on oil platforms. Additionally, to ensure the safety of operations in these potentially explosive atmospheres,
