Explosion Proof Enclosures

Explosion Proof Pressurized Distribution Cabinets

Our explosion proof pressurized distribution cabinets are manufactured according to the highest international standards and fitted with the explosion proof electrical components.

Suitable for use in Zone 1, Zone 2, Zone 21 and Zone 22

• Style IIC boxes provided with aluminum plate cover as standard, allowing for field addition of cover device holes

• Stainless steel cover bolts (Style IIC only)

• Ground joint cover opening provides maximum opening for pulling wires or mounting equipment

• Walls of bodies may be drilled and tapped for conduit entries as shown in listings

• Stud bolts in diagonally opposite corners of body aid in aligning cover to body during installation (not furnished with hinged covers)

• All Style C bodies are provided with captive, triple-lead, quick-release hex head stainless steel bolts with spring loaded action which provides clear indication that cover bolts are fully retracted from the body

• External flange design – wide unobstructed cover opening provides a completely accessible interior for wiring and electrical equipment

• Square corners of enclosure body provide maximum interior space and area for conduit openings

• Internal grounding lug provides a means to ground enclosed equipment

• Special neoprene cover gasket provides a watertight seal to meet IEC requirements, and provides superior protection for enclosed equipment against water/corrosion

• Enclosures are machined for field installed mounting plates

• Detachable mounting feet provide mounting flexibility; no need to replace enclosure if mounting feet are broken

• Optional stainless steel hinges provide convenient and easy access for inspection, maintenance and systems changes

• Enclosures are machined to accept field installed hinges

• Standard materials

• Body and cover – copper-free aluminum

• Gasket – neoprene

• Cover bolts – stainless steel (Style IIC);
